Elliptical heads

ASME axis ratio (2:1)
Diameter: 21,3  until   1600 mm
Use gauges: until   160 mm
NFE axis ratio (1,9:1)
Hot or cold formed / annealed

Further information

Stepped edge Bead sketches


da = Outer diameter
di = Inner diameter
h1 = Stepped-edge height
h2 = Dish height
h3 = Total height innen
r1 = Dish radius
s = Wall thickness
