Normal dished heads

(r1 = da, r2 = 15 bis 50 mm)
Diameter: 300  until   1600 mm
Use gauges: until   160 mm
Hot or cold formed

Further information

Stepped edge Bead sketches

Legend

da = Outer diameter
h1 = Stepped-edge height
h2 = Dish height
h3 = Total height innen
r1 = Dish radius
r2 = Knuckle radius
s = Wall thickness
